10PCS 10W 6V 12V 10W LED XPE XP-E 4 Chips Beads Chip Car Light instead of XLM Red Green Blue Yellow Beads with 20MM Cooper PCB
REMARK: due to the system reason, "Neutral White"="White"."RGBW"="RGB".If you want"2R2B"/"2B2W",pls click"Changeable"and leave me a message.If you want"Royal Blue",pls also click"Blue"and leave a message. If you have any better DIY Idea,pls fell free to contact me.we can custom products for you.
Package Include:
10pcs 6V/12V 10W 4pcsXPE chips as you choosed.
XP-E High Efficiency White LEDs extend the light output and efficacy of the award-winning XP-E LED family, enabling luminaire designs that use up to 50 percent fewer LEDs for a lower system cost.
XP-E High Efficiency White LEDs deliver up to 148 lumens in cool white (6500K) and 114 lumens in warm white (3000K) at 1W. In addition to light output and efficacy improvements, XP-E HEW LEDs feature a reduced thermal resistance of 6 °C/W. XP-E High Efficiency White LEDs are available in the same white variations as XP-E LEDs, including Standard White, Outdoor White and 80-CRI White.
Parameter Description for White/Cool White/Warm White
LED Type:4pcs XPE LED Chips
Voltage :6V/12V
Current: 350mA-2A(6V) 350mA-1A(12V)
Emitter Color:White/Cool White/Warm White
Color temperature:4000-4500K/6000-6500K/3000-3200K
Beam Angle: 115 degrees
Lens color: water clear
PCB board: Diameter 20mm Cooper PCB base
Resin (Mold): Silicone Resin
Certificate: CE&ROSH
LifeSpan Time : > 50,000 hours
Parameter Description forRed/Green/Blue/Yellow(Amber)
LED Type:4pcs XPE LED Chips
Voltage :6V/12V
Current: 350mA-2A(6V) 350mA-1A(12V)
Emitter Color:Red/Green/Blue/Yellow(Amber)
Color temperature :620-630nm/520-535nm/465-485nm/585-595nm
Beam Angle: 115 degrees
Lens color: water clear
PCB board: Diameter 20mm Cooper PCB base
Resin (Mold): Silicone Resin
Certificate: CE&ROSH
LifeSpan Time : > 50,000 hours
Without exceeding 30 ° C/85% relative humidity, infinite life
Can reflow - meets JEDEC J-STD-020C standard Electrically neutral thermal path
Compliance with RoHS and REACh specification
UL certified components(E349212)
Attention to the heat,working temperature maintained at 50 degrees Celsius or lower as possible
Features:
- Very low heat generating, saving energy, environmentally friendly.
- Long service life.
- Low consumption, high brightness.
- Comfortable light source, harmless for skin and eyes.
- Great for making light sources for fish tank, decoration light, etc
- Made of high quality material, durable for daily us
,
